AMS 2 Adjustable Feeder Bottom Kit & 4 to 1 Tensioner

AMS 2 Adjustable Feeder Bottom Kit & 4 to 1 Tensioner

$54.99 USD
$54.99 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Aftermarket Mechanical TPU compatible modification system for Bambu AMS (Gen 2)

Compatible with P1S, X1C. If found to work with other machines let us know what you did.

Improve TPU feeding. Keep your OEM setup.

The AMS Pro Feed System is a precision-engineered bottom-end upgrade designed to solve common filament feeding issues—especially with TPU—without modifying your factory spring.

This is a clean mechanical alternative to popular spring mods, delivering consistent performance through refined geometry and controlled flexibility instead of trial-and-error tension changes.

PDF Instructions will be emailed with purchase

Why Choose This Over Spring Mods?

  • No spring swapping or sourcing parts
  • Uses OEM components exactly as designed
  • Cleaner, repeatable, and more controlled solution

Comes in pack of 4

Must go into the Preferences settings at the top left, scroll down then click skip AMS black list check. This gives you full access to your AMS

Hint! Use TPU for AMS preset setting for best results!





All original plastic types useable with this kit.



AMS TPU Setup & Usage Notes (Important)

For best results when using TPU with this upgrade:

  • Select “TPU for AMS” in your printer settings (not the standard TPU preset). This allows the printer to handle the material more reliably through the AMS system.
  • TPU performance can vary by brand — Sunlu TPU 95A has provided the most consistent results in testing.
  • Dry your filament before use. Moisture in TPU can cause feeding issues and inconsistent behavior.

Feeding & Setup Tips:

  • Start with the feeder fully open (no tension), then slowly tighten until the filament feeds smoothly without slipping or binding during retraction.
  • Using PTFE tubing with a smaller inner diameter (2.0–2.5mm ID) is highly recommended. TPU performs best with minimal movement and reduced internal space.

Due to the flexible nature of TPU, proper setup is important to ensure smooth feeding through the AMS system.

Compatible with ALL original AMS filament

Compatible with P1S, X1C. If found to work with other machines let us know what you did.

Difficulty: Medium - Hard

Not affiliated by Bambu Labs

Made with ASA

View full details

About the product

Why This Upgrade Works

Most TPU “fixes” rely on swapping or modifying springs,
which can lead to inconsistent results.

This system takes a different approach:

  • Maintains OEM spring behavior
  • Improves filament path and pressure consistency
  • Uses engineered rigid structure (ASA)

Result: smoother feeding, less slipping, and more reliable
prints—without guesswork.

What Problems It Solves

  • Soft
    Plastics such as TPU95A not being able to pass the feeder unit
  • Retraction
    issues (Soft TPU) during multi-material prints
  • Poor
    tension interaction with flexible filaments

Key Features

OEM-Compatible Design

Works with your existing factory spring and hardware—no
replacements required.

Mechanical TPU Optimization

Operation Notes

As this is a mechanical upgrade, users may notice
differences in operation compared to stock:

  • Slight
    changes in sound profile
  • More
    direct or “aggressive” mechanical feedback during feeding

These changes are normal and are a result of improved
filament engagement and controlled tension behavior. No functional issues have
been observed during testing.

Best For

  • TPU95A printing through AMS
  • Users experiencing slipping or inconsistent feeding
  • Those who want to avoid spring modifications
  • Hobbyists and experimental users looking to push AMS performance further

Performance Benefits

  • More consistent filament feeding
  • Reduced slipping and grinding
  • Improved reliability in multi-material prints
  • No need to replace or modify OEM spring

Lubrication-Ready System

Designed to operate with light lubrication for improved
consistency and reduced friction.

What’s Included

  • Full upgraded feeder component set (4 AMS 2 channels)
  • Designed to reuse OEM screws, pins, and spring

Installation

  • Time:
    ~20–45 minutes
  • Skill Level: Basic to Intermediate
  • Mods Required: Smaller PTFE Tubing 2mm

Drop-in design using existing AMS 2 mounting points.

Recommended Settings

Tested using Bambu default TPU for AMS settings with
minor tuning adjustments.

Testing & Compatibility

  • Tested with TPU 95A
  • Performance with other flexible or specialty filaments may vary
  • Additional tuning may be required depending on material

Disclaimer

This is an aftermarket upgrade and is not affiliated with or
endorsed by Bambu Lab.

By purchasing and installing this product, you acknowledge:

  • Installation and use are at your own risk
  • Performance may vary depending on setup and materials
  • The seller is not responsible for damage resulting from installation,
    modification, or misuse
  • By purchasing, installing, or using this product, you acknowledge and agree
    to all terms outlined above, including proper installation, usage at your
    own risk, and limitation of liability.
  • By purchasing and installing this product you agree that it is not a
    guarantee that it will work with softer plastics than TPU95A

IMPORTANT: Small non-structural tab may be separated during shipping. Does NOT affect function.
